极速全自动瓶盖滴塑机

极速全自动瓶盖滴塑机
High-speedAutomatic Plastic Droppding Machine



基本配置Basic Equipment 控制系统：进口PLC+温控模版+进口触摸屏+进口光电监测 Control systerm:lmported PLC+Temperatur control module+lmported touch screen
气动系统：进口SMCAir drive system:lmport SMC 挤出系统：硬齿面减速器+变频器+节能加热器 Extrusion system:Hardened-gear speed reducer+lnverucer+lnverter+Energy-saving heater

功能　 Function

低气压报警/模具数据存储
Low pressure alarm/mould data storage

温度PID控制，可确保塑胶制品的高品质、高精度要求
temperature PID control,make sure the high quality and high accuracy

电加热温度不到设定温度时，有冷料防止启动功能。
If the electric heating temperature do not reach at the setting temperature,the cold slug prevent from starting.

监控、计数、报警、故障自我诊断。
monitor,calculata,alarm,self-diagnosis failures device.

温差报警
temperature deviation alarm

可选装滴塑检测系统
plastic drop detection system is optional

技术参数Technical parameters

最小瓶盖直径：Min.cap diameter:25mm

最大瓶盖直径：Max.cap diamcrer:30mm

最小瓶盖高度：Min.cap height:10mm

最大瓶盖高度：Max.cap height:30mm

日产:daily output:720000-860000caps

总功率:poWer:12.8KW

电源电压power supply　 voltage:3AC/N/PE 　220V/60Hz　 380V/50Hz 　415V/50Hz　 440V/60Hz

压缩空气Compressed air.0.8MPa 1.5m3(自备self-supply)

模具腔数Mold number:24腔cavity

外形尺寸:Contour dimensions:6500X1800X2600mm

机重:Machine weight:3T
